Forged Globe Valve

Fangwen Forged Globe Valves are designed and manufactured strictly to International Standards API 602, ASME B16.34 or DIN 3202, Featured with compact structure & Low emission service, and supplied by Fangwen are with the following features:

» Manufactured under ISO 9001:2008 Management System, with CE PED & API 6D Certified

» Design & Manufactured to API 602, ASME B16.34 or DIN3202

» P.T Ratings to ASME B16.34

» Face to Face dimensions to ASME B16.10

» Flanged Ends to ASME B16.5

» Butt-weld Ends to ASME B16.25

»- Threaded Ends to ASME B1.20.1

» Socket-weld Ends to ASME B16.11

»Valves Marking to MSS SP-25

» Inspect & Tested to API 598

» Sizes Ranges from 1/2” thru 2”

» Pressure Ratings from Class 150 to Class 1500, PN16 to PN260

» Structures in Bolted Cover, Outside Screw and Yoke

» Ends Connections in Flanged R.F or RTJ, Threaded NPT, BSPT, Welded S.W, B.W and Grooved

» Body Materials available in Carbon Steel, Alloy Steel, Stainless Steel, Duplex & Super Duplex Steel, Special Materials in Monel, Alu. Bronze etc.

» Trim Materials available in 13%Cr, F11, F22, SS304, SS304L, SS316, SS316L and other specials

» Actuations can be equipped with Handwheel, Electric / Pneumatic or Hydraulic Actuators

» Optional Bypass system, Live Loading Packing & O-ring Seal available upon request.

Fangwen offers Forged Globe Valve covering, but not limited to

▲Forged Steel Globe Valve ▲Stainless Steel Globe Valve ▲Pressure Seal Globe Valve

▲Cryogenic Globe Valve ▲T Globe Valve ▲Y Globe Valve ▲Bronze Globe Valve

▲Bellow Sealed Globe Valve

Y Globe Valve

Fangwen Y Globe Valves are designed and manufactured strictly to International Standards API 602, ASME B16.34 or DIN3202, designed as Y Type between inlet and outlet to suitable for the Y Angle pipe, Featured with compact structure & Tight shut off service.

Fangwen Y Globe Valves are with main Features as below:

» Design & Manufactured to API 602, ASME B16.34 or DIN3202 ◆ P.T Ratings to ASME B16.34

» Face to Face dimensions to ASME B16.10 ◆ Flanged Ends to ASME B16.5

» Butt-weld Ends to ASME B16.25 ◆ Valves Marking to MSS SP-25

» Inspect & Tested to API 598

» Sizes Ranges from 1/2” thru 2”

» Structured in Bolted Cover, Outside Screw and York

» Pressure Ratings from Class 150 to Class 1500, PN16 to PN260

» Ends Connections in Flanged R.F or RTJ, Butt-welded and Screwed

» Body Materials available in Forged Carbon Steel, Forged Low Carbon Steel, Forged Alloy Steel, Forged Stainless Steel, Forged Duplex & Super Duplex Steel, Special Materials in Forged Monel, Alu. Bronze etc.

» Trim Materials available in 13%Cr, F11, F22, SS304, SS304L, SS316, SS316L and other specials

» Actuations can be equipped with Handwheel, Electric / Pneumatic or Hydraulic Actuators

» Optional Globe Check, Bypass system, Live Loading Packing & O-ring Seal
