Forged Globe Valve
Fangwen Forged Globe Valves are designed and manufactured strictly to International Standards API 602, ASME B16.34 or DIN 3202, Featured with compact structure & Low emission service, and supplied by Fangwen are with the following features:
» Manufactured under ISO 9001:2008 Management System, with CE PED & API 6D Certified
» Design & Manufactured to API 602, ASME B16.34 or DIN3202
» P.T Ratings to ASME B16.34
» Face to Face dimensions to ASME B16.10
» Flanged Ends to ASME B16.5
» Butt-weld Ends to ASME B16.25
»- Threaded Ends to ASME B1.20.1
» Socket-weld Ends to ASME B16.11
»Valves Marking to MSS SP-25
» Inspect & Tested to API 598
» Sizes Ranges from 1/2” thru 2”
» Pressure Ratings from Class 150 to Class 1500, PN16 to PN260
» Structures in Bolted Cover, Outside Screw and Yoke
» Ends Connections in Flanged R.F or RTJ, Threaded NPT, BSPT, Welded S.W, B.W and Grooved
» Body Materials available in Carbon Steel, Alloy Steel, Stainless Steel, Duplex & Super Duplex Steel, Special Materials in Monel, Alu. Bronze etc.
» Trim Materials available in 13%Cr, F11, F22, SS304, SS304L, SS316, SS316L and other specials
» Actuations can be equipped with Handwheel, Electric / Pneumatic or Hydraulic Actuators
» Optional Bypass system, Live Loading Packing & O-ring Seal available upon request.
Fangwen offers Forged Globe Valve covering, but not limited to
▲Forged Steel Globe Valve ▲Stainless Steel Globe Valve ▲Pressure Seal Globe Valve
▲Cryogenic Globe Valve ▲T Globe Valve ▲Y Globe Valve ▲Bronze Globe Valve
▲Bellow Sealed Globe Valve
T Globe Valve
Fangwen T Globe Valves is named from the T Type Disc, are designed and manufactured to ensure leakage of less than 100 ppm (parts per million) of volatile organic compounds.
Fangwen T Globe Valves are with main Features as below:
» Size Ranges: 1/2” through 2”
» Pressure Ratings: ANSI #150 to 2500
» Standards compliance: BS1873, ASME B16.34 or equivalents
» Materials: A105, F11, F22, F5, F304, F316, F304L, F316L, F51 and etc.
» Ends Connections: Flanged(FF, RF, RTJ) to international standards
» OS&Y, Outside Stem and Yoke
» Metal-sealed(API Trim # 1, #5, #8, #10 and etc.)
» Optional Locking Device or Stem Extension
» Optional Direct Mounting to ISO 5211
» Reduce Port
