Forged Globe Valve

Fangwen Forged Globe Valves are designed and manufactured strictly to International Standards API 602, ASME B16.34 or DIN 3202, Featured with compact structure & Low emission service, and supplied by Fangwen are with the following features:

» Manufactured under ISO 9001:2008 Management System, with CE PED & API 6D Certified

» Design & Manufactured to API 602, ASME B16.34 or DIN3202

» P.T Ratings to ASME B16.34

» Face to Face dimensions to ASME B16.10

» Flanged Ends to ASME B16.5

» Butt-weld Ends to ASME B16.25

»- Threaded Ends to ASME B1.20.1

» Socket-weld Ends to ASME B16.11

»Valves Marking to MSS SP-25

» Inspect & Tested to API 598

» Sizes Ranges from 1/2” thru 2”

» Pressure Ratings from Class 150 to Class 1500, PN16 to PN260

» Structures in Bolted Cover, Outside Screw and Yoke

» Ends Connections in Flanged R.F or RTJ, Threaded NPT, BSPT, Welded S.W, B.W and Grooved

» Body Materials available in Carbon Steel, Alloy Steel, Stainless Steel, Duplex & Super Duplex Steel, Special Materials in Monel, Alu. Bronze etc.

» Trim Materials available in 13%Cr, F11, F22, SS304, SS304L, SS316, SS316L and other specials

» Actuations can be equipped with Handwheel, Electric / Pneumatic or Hydraulic Actuators

» Optional Bypass system, Live Loading Packing & O-ring Seal available upon request.

Fangwen offers Forged Globe Valve covering, but not limited to

▲Forged Steel Globe Valve ▲Stainless Steel Globe Valve ▲Pressure Seal Globe Valve

▲Cryogenic Globe Valve ▲T Globe Valve ▲Y Globe Valve ▲Bronze Globe Valve

▲Bellow Sealed Globe Valve

Stainless Steel Globe Valve

Fangwen Stainless Steel Globe Valve are designed and manufactured strictly to International Standards API 602, ASME B16.34, DIN3202 or Equivalent.

Fangwen Stainless Steel Globe Valve are with main Features as below:

» Size Ranges: 1/2” through 2”

» Pressure Ratings: ANSI #150 to 2500

» Standards compliance: API 602, ASME B16.34, DIN3202 or equivalents

» Materials: A182 F304, A182 F316, A182 F304L, A182 F316L, A182 F51

» Ends Connections: Screwed, Welded Ends and Flanged(FF, RF, RTJ) to international standards

» OS&Y, Outside Stem and Yoke

» Metal-sealed(API Trim # 1, #5, #8, #10 and etc.)

» Optional Locking Device or Stem Extension

» Optional Bolted Bonnet, Welded Bonnet or Pressure Sealed Bonnet

» Optional Direct Mounting to ISO 5211

» Reduce Port
