Expanding Gate Valve

Fangwen Expanding Gate Valves are manufactured with a full bore port and with 2-piece (gate + segment) obturator designed for a positive, bubble tight shut off upstream and downstream under both low and high differential pressure. Double block and bleed capability and high robustness are standard feature of this seat design. The smooth, continuous bore minimizes turbulence within the valve and when in the open position it produces a pressure drop equivalent to a portion of pipe of same length and diameter. The seat faces are outside the flow stream and therefore protected from the erosive action of the flow. Pigs and scrapers can be run through the valve without damage.

Fangwen offers Cast Gate valves in One piece uni-body, All Cast Gate valves manufactured and supplied by Fangwen are with the following features:

» Manufactured under ISO 9001:2008 Management System, with CE PED & API 6D Certified

» Standards compliance to API 6d, API 6A or equivalents

» Flanged Ends precised to international standards ASME B16.5, BS EN 1092, BS4504

» Rising Stem and Non Rising Handwheel

» Optional Locking Device or Stem Extension

» Solid or Flexible wedge options

» Bolted Bonnet or Pressure Sealed Bonnet

» Soft seated or metal-seated

» Optional Locking Device or Stem Extension

» Optional Direct Mounting to ISO 5211

» Full Port design

» NACE MR-01-75

Fangwen offers Expanding Gate Valves including, but not limited to

▲ Resilient Seat Expanding Gate Valve ▲ Metal Seat Expanding Gate Valve

Metal Seat Expanding Gate Valve

Fangwen Metal Seat Expanding Gate Valves is designed for critical service. This full bore, through-conduit gate valve features a mechanically sealing gate to assure positive shut-off. The valve can be trimmed to meet most specifications that require handling a wide range of products and services. The extensions and adaptation for actuation are options regularly requested and provided.

Fangwen Metal Seat Expanding Gate Valves are with main Features as below:

» Size Ranges: 2” through 48”

» Pressure Ratings: ANSI #150 to 2500

» Standards compliance: API 6D, API 6A or equivalents

» Materials: Cast Carbon Steel, Cast Stainless Steel, Cast Duplex or Other Specials

» Ends Connections: Flanged (FF, RF, RTJ) to international standards

» OS&Y, Outside Stem and Yoke

» Metal-sealed( 13Cr, STL, 316, 304 and etc.)

» Optional Locking Device or Stem Extension

» Optional Direct Mounting to ISO 5211

» Full Port
