Forged Globe Valve

Fangwen Forged Globe Valves are designed and manufactured strictly to International Standards API 602, ASME B16.34 or DIN 3202, Featured with compact structure & Low emission service, and supplied by Fangwen are with the following features:

» Manufactured under ISO 9001:2008 Management System, with CE PED & API 6D Certified

» Design & Manufactured to API 602, ASME B16.34 or DIN3202

» P.T Ratings to ASME B16.34

» Face to Face dimensions to ASME B16.10

» Flanged Ends to ASME B16.5

» Butt-weld Ends to ASME B16.25

»- Threaded Ends to ASME B1.20.1

» Socket-weld Ends to ASME B16.11

»Valves Marking to MSS SP-25

» Inspect & Tested to API 598

» Sizes Ranges from 1/2” thru 2”

» Pressure Ratings from Class 150 to Class 1500, PN16 to PN260

» Structures in Bolted Cover, Outside Screw and Yoke

» Ends Connections in Flanged R.F or RTJ, Threaded NPT, BSPT, Welded S.W, B.W and Grooved

» Body Materials available in Carbon Steel, Alloy Steel, Stainless Steel, Duplex & Super Duplex Steel, Special Materials in Monel, Alu. Bronze etc.

» Trim Materials available in 13%Cr, F11, F22, SS304, SS304L, SS316, SS316L and other specials

» Actuations can be equipped with Handwheel, Electric / Pneumatic or Hydraulic Actuators

» Optional Bypass system, Live Loading Packing & O-ring Seal available upon request.

Fangwen offers Forged Globe Valve covering, but not limited to

▲Forged Steel Globe Valve ▲Stainless Steel Globe Valve ▲Pressure Seal Globe Valve

▲Cryogenic Globe Valve ▲T Globe Valve ▲Y Globe Valve ▲Bronze Globe Valve

▲Bellow Sealed Globe Valve

Forged Steel Globe Valve

Fangwen Forged Steel Globe Valves are designed and manufactured strictly to International Standards API 602, ASME B16.34, DIN3202 or Equivalent, a compact but extremely sturdy design for high pressure-temperature service, Solid CoCr alloy wedge (optional) ensures low friction and long service life, packing rings are precompressed to 4000 psi to provide a high integrity seal, for welded bonnet valves, the bonnet is threaded in and torqued to an engineered torque value and the body bonnet joint is strength-welded, offering double protection against leakage. (Body/bonnet threads and strength-weld), fully guided wedge reduces wear on seating surfaces, Optional design available with double packing, leak-off connection, live-loading and a packing blowout for easy removal of old packing.

Fangwen Forged Steel Globe Valves are with main Features as below:

» Size Ranges: 1/2” through 2”

» Pressure Ratings: ANSI #150 to 2500

» Standards compliance: API 602, ASME B16.34, DIN3202 or equivalents

» Materials: Forged Carbon Steel, Forged Stainless Steel, Forged Duplex or Other Specials

» Ends Connections: Screwed, Welded Ends and Flanged(FF, RF, RTJ) to international standards

» OS&Y, Outside Stem and Yoke

» Metal-sealed(API Trim # 1, #5, #8, #10 and etc.)

» Optional Locking Device or Stem Extension

» Optional Bolted Bonnet, Welded Bonnet or Pressure Sealed Bonnet

» Optional Direct Mounting to ISO 5211

» Reduce Port
