High Performance Butterfly Valve

The high performance valve feature an eccentrically mounted disc and are known for their wide application range and shutoff capability. They are available for a variety of control and isolation service from cryogenic to high temp and pressure classes to ASME CL2500 and sizes from NPS 2 to 72.

The high performance butterfly valve are designed for isolation on/off service as well as low tier control. The POSI-SEAL valves feature keyed, double D or square valve shafts. The POSI-SEAL valves are available in sizes NPS 2 to 72, pressure classes up to CL2500. Shutoff is provided by a variety of seals which include metal, PTFE and fire-tested and cryogenic.

STANDARDS COMPLIANCE:

» ISO 5752, BS 5155, API 609, MSS-SP-68, ASME B16.10, ASME B16.5, DIN 3202

» Materials: Carbon Steel, Stainless Steel, Aluminium Bronze, Monel, Hastelloy, Titanium, Duplex, Super Duplex and other specials.

» Pressure Ratings: ANSI 150# to ANSI 1500#

» Size Ranges: 2" to 140"- 50mm to 3500mm (Larger sizes upon request)

» Ends Connections: Wafer, Lugged, Double Flanged, Butt Weld or Grooved

» optional Seat rings: Resilient RPTFE; Metal seated INCONEL (Fire safe on application)

» actuations: Manual, Pneumatic, Electric, Hydraulic (Counterweight) & Electro-hydraulic

Fangwen offers High Performance Butterfly Valves including, but not limited to

▲Wafer High Performance Butterfly Valve

▲Lug High Performance Butterfly Valve

▲ Flange High Performance Butterfly Valve

Flange High Performance Butterfly Valve

The Fangwen Flange High Performance Butterfly Valves provides outstanding performance under extreme pressure and temperature conditions. The double offset design provides an approximate equal percentate flow characteristic and facilitates tight class VI shut-off, reslient-seated construction or class IV with metal seals.

The Fangwen High Performance valves are available in Soft Seat (Up to 200°C depending on size and pressure), and Metal Seat (Up to 600°C) variants (fire safe on application).

Fangwen Flange High Performance Butterfly Valves are with main Features as below:

» ISO 5752, BS 5155, API 609, MSS-SP-68, ASME B16.10, ASME B16.5, DIN 3202

» Materials: Carbon Steel, Stainless Steel, Aluminium Bronze, Monel, Hastelloy, Titanium, Duplex, Super Duplex and other specials.

» Pressure Ratings: ANSI 150# to ANSI 1500#

» Size Ranges: 2" to 140"- 50mm to 3500mm (Larger sizes upon request)

» Ends Connections: RF, RTJ

» optional Seat rings: Resilient RPTFE; Metal seated INCONEL (Fire safe on application)

» actuations: Manual, Pneumatic, Electric, Hydraulic (Counterweight) & Electro-hydraulic
