Cast Gate Valve

Cast Gate valves are characterized as having either a rising or a non rising stem. Rising stems provide a visual indication of valve position because the stem is attached to the gate such that the gate and stem rise and lower together as the valve is operated. Non rising stem valves may have a pointer threaded onto the upper end of the stem to indicate valve position, since the gate travels up or down the stem on the threads without raising or lowering the stem. Non rising stems are used underground or where vertical space is limited.

Fangwen offers Cast Gate valves in one piece unit-body, All Cast Gate valves manufactured and supplied by Fangwen are with the following features:

» Manufactured under ISO 9001:2008 Management System, with CE PED & API 6D Certified

» Standards compliance to API 600, ASME B16.34, DIN 3202 or equivalents

» Flanged Ends precise to international standards ASME B16.5, BS EN 1092, BS4504

» Rising Stem, Non Rising Stem and Non Rising Hand wheel

» Optional Locking Device or Stem Extension

» Solid or Flexible wedge options

» Bolted Bonnet or Pressure Sealed Bonnet

» Soft seated or metal-seated

» Optional Locking Device or Stem Extension

» Optional Direct Mounting to ISO 5211

» Full Port design

» NACE MR-01-75

Fangwen offers Cast Gate Valve including, but not limited to

▲ Cast Steel Gate Valve ▲Stainless Steel Gate Valve ▲Cast Iron Gate Valve

▲Bellow Sealed Gate Valve ▲Cryogenic Gate Valve ▲Pressure Seal Gate Valve

▲Cast Bronze Gate Valve ▲Investment Casting Gate Valve

Cast Steel Gate Valve

Fangwen is an international leading manufacturer and supplier of industrial valves in the world. Our primary goal is to provide a unique solution for the services of Oil, Gas, Nuclear, Refinery, Chemical, Marine, Potable Water, Waste Water, Sewage, Power Station and Pipeline Industries.

Fangwen Cast Steel Gate Valves are with main Features as below:

» Size Ranges: 1 1/2” through 48”

» Pressure Ratings: ANSI #150 to 2500

» Standards compliance: API 600, ASME B16.34 or equivalents

» Materials: Cast Carbon Steel, Cast Stainless Steel, Cast Duplex or Other Specials

» Ends Connections: Flanged (FF, RF, RTJ) to international standards

» OS&Y, Outside Stem and Yoke

» Metal-sealed(API Trim # 1, #5, #8, #10 and etc.)

» Optional Locking Device or Stem Extension

» Optional Direct Mounting to ISO 5211

» Full Port
