Bellow Sealed Globe Valve

You are here: Home » Products » Globe Valve » Bellow Sealed Globe Valve

Product Name: Bellow Sealed Globe Valve

--------------------------------------------------------------------------------------------------

Contact Details:

Contact Person: Mr. BURT DAI

E-mail: sales@yiyuvalve.com

Tel: +86-130 577 44 163

Tel: +86-577 868 99 212

--------------------------------------------------------------------------------------------------

OnLine Service：

Print this Page	Bookmark this
Skype Online	E-mail Us
PDF Download
【Prev Products】	【Next Products】

Description	Send Inquiry

Forged Globe Valve

Fangwen Forged Globe Valves are designed and manufactured strictly to International Standards API 602, ASME B16.34 or DIN 3202, Featured with compact structure & Low emission service, and supplied by Fangwen are with the following features:

» Manufactured under ISO 9001:2008 Management System, with CE PED & API 6D Certified

» Design & Manufactured to API 602, ASME B16.34 or DIN3202

» P.T Ratings to ASME B16.34

» Face to Face dimensions to ASME B16.10

» Flanged Ends to ASME B16.5

» Butt-weld Ends to ASME B16.25

»- Threaded Ends to ASME B1.20.1

» Socket-weld Ends to ASME B16.11

»Valves Marking to MSS SP-25

» Inspect & Tested to API 598

» Sizes Ranges from 1/2” thru 2”

» Pressure Ratings from Class 150 to Class 1500, PN16 to PN260

» Structures in Bolted Cover, Outside Screw and Yoke

» Ends Connections in Flanged R.F or RTJ, Threaded NPT, BSPT, Welded S.W, B.W and Grooved

» Body Materials available in Carbon Steel, Alloy Steel, Stainless Steel, Duplex & Super Duplex Steel, Special Materials in Monel, Alu. Bronze etc.

» Trim Materials available in 13%Cr, F11, F22, SS304, SS304L, SS316, SS316L and other specials

» Actuations can be equipped with Handwheel, Electric / Pneumatic or Hydraulic Actuators

» Optional Bypass system, Live Loading Packing & O-ring Seal available upon request.

Fangwen offers Forged Globe Valve covering, but not limited to

▲Forged Steel Globe Valve ▲Stainless Steel Globe Valve ▲Pressure Seal Globe Valve

▲Cryogenic Globe Valve ▲T Globe Valve ▲Y Globe Valve ▲Bronze Globe Valve

▲Bellow Sealed Globe Valve

Bellow Sealed Globe Valve

The Fangwen Bellow Sealed Globe valves have been solving fluid control problems in Steam, Boiling and other general industrial applications for over 30 years. Bellows seal gate valves reduce fugitive emissions of toxic, lethal, or regulated fluids/gases, minimize maintenance, reduce life cycle costs, and optimize productivity in process plants. This includes steam, cryogenic, and vacuum systems.

STANDARDS COMPLIANCE:

» DIN 3356, BS 5160, ASME B16.34, API 602

» ASME B16.10, EN558-1 / DIN 3202

» ASME B16.5, ASME B16.11, ASME B1.20.1, DIN 2543~2545, EN 12627

» ISO 5208, API 598, DIN 3230, MSS SP-117

» Sizes: DN15 through DN50

» Body Styles: End connections Flanged, Welded or Threaded Ends

» Pressure Class: ANSI CL150 to CL900, PN16 to PN64.

» Actuations: Hand wheel, Electric, Pneumatic, Hydraulic or E-Hydraulic
